AGRICULTURAL MACHINERY
MVDE India manufactures a wide range of off-highway diesel engines for agricultural purposes.
Globally, MVDE's diesel engines are trusted by numerous industry leaders. MVDE builds a multitude of diesel engines for agriculture ranging from 12hp to 50 hp. Our diesel engines are designed keeping in mind the growing demand for Small & Medium size tractors used in horticulture and precision farming, especially in India, the world’s largest tractor market.
MVDE's diesel engines are used in various agricultural machinery around the globe. Our diesel engines for tractors, mini harvesters, boom sprayers etc. are rugged, robust, and reliable, and are engineered to perform excellently when you most need it.
| Engine Model | MVL3E | MVS3L2 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Type | 4-Cycle Water-Cooled Diesel Engine | |||||||||
| Aspiration | Natural Aspirated | |||||||||
| Number of Cylinders | 3 | 3 | ||||||||
| Bore and Stroke (mm) | 76 X 70 | 78 X 92 | ||||||||
| Displacement (cc) | 952 | 1318 | ||||||||
| Combustion system | Swirl chamber | |||||||||
| Rated output(Note) in kW (HP) |
13.4 (18) | 15.3 (20.5) | 16.3 (21.9) | 17.8 (23.9) | 18.4 (24.7) | 16.4 (22.0) | 19.6 (26.3) | 19.9 (26.7) | 21.3 (28.6) | 22.3 (29.9) |
| Rated Speed (rpm) | 2700 | 3000 | 2200 | 2400 | 2500 | 2600 | 2600 | 2700 | 2800 | 3000 |
| Engine Model | MVS4L2 | MVS4L2-T | |||||
|---|---|---|---|---|---|---|---|
| Type | 4-Cycle Water-Cooled Diesel Engine | ||||||
| Aspiration | Natural Aspirated | Turbocharged | |||||
| Number of Cylinders | 4 | ||||||
| Bore and Stroke (mm) | 78 X92 | ||||||
| Displacement (cc) | 1758 | ||||||
| Combustion system | Swirl chamber | ||||||
| Rated output(Note) in kW (HP) |
21.7 (29) | 23.7 (31.8) | 26.5 (35.5) | 27.5 (36.9) | 30.3 (40.6) | 34 (45.6) | 36.8 (49.4) |
| Rated Speed (rpm) | 2200 | 2400 | 2700 | 2800 | 3000 | 2800 | 3000 |
- All ratings are without fan. Output may vary + or -5%
All spec & ratings are subject to change without prior notice
