AGRICULTURAL MACHINERY
Demand for Small & Medium tractors keep increasing owing to growth in horticulture and precision farming especially in India, the world’s largest tractor market. These tractors need a compact engine with maximum power to weight ratio. MITSUBISHI DIESEL ENGINES are known for Compactness, Light weight & Maximum power. No surprise, it is already a preffered choice of many tractor manufacturers!
| Engine Model | MVL3E | MVS3L2 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Type | 4-Cycle Water-Cooled Diesel Engine | |||||||||
| Aspiration | Natural Aspirated | |||||||||
| Number of Cylinders | 3 | 3 | ||||||||
| Bore and Stroke (mm) | 76 X 70 | 78 X 92 | ||||||||
| Displacement (cc) | 952 | 1318 | ||||||||
| Combustion system | Swirl chamber | |||||||||
| Rated output(Note) in kW (HP) |
13.4 (18) | 15.3 (20.5) | 16.3 (21.9) | 17.8 (23.9) | 18.4 (24.7) | 16.4 (22.0) | 19.6 (26.3) | 19.9 (26.7) | 21.3 (28.6) | 22.3 (29.9) |
| Rated Speed (RPM) | 2700 | 3000 | 2200 | 2400 | 2500 | 2600 | 2600 | 2700 | 2800 | 3000 |
| Engine Model | MVS4L2 | MVS4L2-T | |||||
|---|---|---|---|---|---|---|---|
| Type | 4-Cycle Water-Cooled Diesel Engine | ||||||
| Aspiration | Natural Aspirated | Turbocharged | |||||
| Number of Cylinders | 4 | ||||||
| Bore and Stroke (mm) | 78 X92 | ||||||
| Displacement (cc) | 1758 | ||||||
| Combustion system | Swirl chamber | ||||||
| Rated output(Note) in kW (HP) |
21.7 (29) | 23.7 (31.8) | 26.5 (35.5) | 27.5 (36.9) | 30.3 (40.6) | 34 (45.6) | 36.8 (49.4) |
| Rated Speed (RPM) | 2200 | 2400 | 2700 | 2800 | 3000 | 2800 | 3000 |
- All ratings are without fan. Output may vary + or -5%
All spec & ratings are subject to change without prior notice
